New build 2023 June delivery
Prıce 17.000.0000 euro
Type ........................................ : Semi Displacement Motor Yacht
Design & Styling .......................... : VYD Studio, Trieste Italy
Naval Architect ........................... : Ginton Naval Architects BV, Haarlem Nederlands
Length hull overall ....................... : 42,729 m
Length waterline ......................... : 40.493 m
Beam (max) ............................... : 8.80 m
Draft ....................................... : 2.70 m
Displacement (100%) ................... : 418 tonnes
Hull construction ......................... : Steel
Superstructure ........................... : Aluminium
Exterior paint system ................... : AkzoNobel International
Classification ............................. : RINA Commercial Yacht, Malta Flag Short Range
Main engines .............................. : 2 x Caterpillar C18
Power ...................................... : 1015 hp @ 2300 rpm
Gearbox ................................... : ZF Marine - ZF 2300
Shaft & propeller ........................ : Teignbridge, 5-blades, Aluminium Bronze, BS1400
Steering gear ............................. : Data DDS 1000 ESC Electro-hydraulic
Exhaust systems .......................... : Soundown
Speed (maximum / cruise) ............. : 14 knots / 11 knots
Range ...................................... : 2300 miles at Cruising Speed
Bow thruster .............................. : ABT-Trac 20’’ with 100HP AC Motor
Stern thruster ............................ : ABT-Trac 16’’ with 63CC Hydraulic Motor
Stabilisers ................................. : ABT-Trac 4-fin 270/16X Zero Speed
Windlasses ................................ : Data DZC 2200 EPL/Kr/5
Capstans ................................... : Data DHC 2200 EPL/Kr/5
Passerelle ................................ : REM Marine
Tendercrane .............................. : Rem Marine
Fuel Total Capacity ...................... : 43.390 litres
Fuel Day Tank Capacity ................. : 1.190 litres
Fresh Water Capacity ................... : 5700 litres
Black / Grey Water Capacity ........... : 10.100 litres
Lube Oil Capacity ........................ : 900 litres
Sludge Oil Capacity ...................... : 900 litres
Watermaker .............................. : Aquaprime ECO T/D 2x400 lt/h
Sewage Treatment Plant ............... : Selmar Blue Sea 4000
Fuel Separator ............................ : Parker Racor RVFS SS Series Fuel Filter
Electrical System ........................ : 400 VAC - 50Hz 3-phase
Generators ................................ : 2 x Caterpillar C4 69 ekW, 1 x Caterpillar C4 51 ekW
Control and Monitoring Systems ....... : Bonning System
Fire Fighting System ..................... : Aerosol System
Air Conditioning & Heating ............. : Domatic Cruise Air Systems
Communication Systems ................... : Furuno System
Navigation Equipment ...................... : Furuno Systen
Galley Equipment ........................ : Miele Professional
Entertainment Systems ................. : Pioneer Professionel
Number of Owner /Guest cabins ...... : 5 (1 Master cabin, 2 VIP cabins and 2 Guest cabin)
Number of Crew cabins ................. : 3 (1 Captain cabin and 2 Crew cabins)
